Spark Shop Ultimate
Part number: 32-832
Pack size: EA
Group: Micro
Type: Button
Amp/Volt: 1.5A - 25VDC / 5A - 250VAC
Size: Mini
Feature 1: Push Button
Feature 2: Off/On (NO / NC)

Part # 32-832
Part # 32-832

Small dimensions suitable for OEM
High Temprature Maximum
Wide choice of heads and actuators
Long Service life
General Purpose -25DegC > 80DegC
Rating 1.5A 25VDC, 5.0A 250VAC

Operating Force Max (OF) - 100g
Releasing Force (RF) - 25g
Operating Position(OP) - 14.7 +/- 0.4
Pre-Travel Max (PT) - 1.2mm
Over-Travel Min (OT) - 1.0mm
Travel Differential(DT) - 0.4mm
