This transmitter remote uses fast frequency hopping (FFH) to allow up to eight transmitters to
be used in the same area. No interference or jamming will occur. The FFH technology is
usually used in very expensive equipment with military and medical applications. This
transmitter is unique providing a low cost, light weight hand held 915MHz FFH transmitter.
This transmitter uses a dual digital coding called Multicode Technology (MCT). This MCT
digitalcoding can be either the 12-way dipswitch or the encrypted coding. The 12-way dip
switchallows for simple programming and involves the user to simply match the 12-way dip
switchon both the transmitter and receiver. The Transmitters 12-way dip switch is found
under the rear cover where the 9V battery is located. The encrypted coding is a random
generatedcode whichis programmed wirelessly to the transmitter and receiver. The
encrypted code isusually usewhen more codes are required for high security applications.
See attached PDFsetupinstructions which are linked at the end of this page for moredetails
on the dipswitchand encrypted coding.
The combination of FFH and MCT technology brings you a very sophisticated transmitter yet
easy to use. This transmitter also allows a mini external antenna to be connected via an SMA
connector which combined with an antenna located near the associated receiver will increase
the line of site transmitting range up to 350 metres.
Features include:
Typical Applications
