Battery Master Switch Marine

Marine-grade, brass case and lever actuator make it simple to use the battery cutoff
switch in boats, emergency vehicles, and heavy-duty trucks Marine On/Off Brass

• 800A Intermittent
• DPST
• UL Rating 707B
• Silver laminated contacts
• Brass Case
• Silver contacts
• Battery terminals 125A continuous, 800A intermittent
• Field terminals 20A Continuous
• Chrome lever actuator
• 2 stud terminals 10-32
• Mounting stem 3/4" - 24 thread
• Mounting stem thickness 46.05mm
• Suits panel thickness up to 23.81mm
• Voltage: 6-36V
• Dimensions H x D: 122 x 67mm
• Modes: On/Off
• Application: Heavy Duty, Marine
