Part number: 32-340
Pack size: EA
Type/Position: Acc/Off/On/Start
Vehicle: ***Petrol Universal
Pin No:
Manufacturer: Pollak

Part # 32-340
Part # 32-340
Part # 32-340

Ignition Starter Switch

Note: Has starter lockout function - see 32-336 link below for switch without starter lockout

OEM on Hyster

All 32-340 switches use the same key making it convenient for fitting to fleets (see 32-342 link below for key)

  • Spring return to ON position - housing tied to ground terminal
  • Battery contact insulated from wiper contact in OFF position
  • High impact base
  • Brass terminals
  • Weather resistant o-ring seal
  • Lip seal prevents moisture from entering contact chamber
  • Heavy chrome plated brass mounting
  • Internally lubricated for longer life
  • Solid copper contacts and wiring
  • One piece zinc die-cast housing spun over terminal base 360 degrees
Typical ratings at 14 volts DC (50,000 cycles)
  • Ignition terminal: 8 amps
  • Accessory terminal: 30 amps (inductive)
  • Start terminal: 75 amps make, 20 amps break
Continuous current carrying capacity - 30 amps at 14 volt
Accessory terminal with number 10 gauge wire
