AM CB Mobile Radio Shallow Flush Mount

Note: This CB is an 40ch. AM 26MHz radio which is not compatible with PRS 80ch. FM 477MHz radios

The GX400 is built tough to withstand some of the harshest environments in the world.
The GX400 can be positioned on the dashboard by flush mount or gimbal bracket mount
as supplied. With a compact mounting depth of only 45mm, it's possible to mount this
compact unit into tight locations where space is limited.

For enhanced clarity and ease of use, the GX400 is equipped with dual speakers - one in
the front panel and a second built into the waterproof speaker mic.

Also available in white, the GX400 is a stylish and versatile addition to your vehicle.

• Waterproof speaker microphone
• Large backlit LCD screen with dimming function
• Channel scanning with memory
• Dual watch and triple watch functions
• Two priority channels
• Multiple mounting options including flush mount and gimbal bracket
• Cabin cover
• Mounting bracket, gimbal knobs and hardware
• Microphone bracket
• DC power lead
• Instruction manual

GENERAL

• Frequency Range TX 26 30 MHz
• Operating Temperature0 - +55
• Modulation AM (A3E)

TRANSMITTER

• Spurious Emission
• Frequency Error1.4 kHz
• Modulation300 Hz to 3 kHz, + 1 3 dB

RECEIVER

• Spurious Response Immunity 55 dB

MECHANICAL SPECIFICATIONS

• Dimensions65 (H) x 75 (D) x 164 (W) mm
• Weight 602 grams
• Power Supply/Supply Voltage: 12 V DC nominal, 10.8 15.6 V DC range
• Ingress Protection rating IPX7

Note: Always test your CB installation with an appropriate SWR meter.
Always check and if need be tune your CB antenna system every time you move it,
every time you add a spring base or change the coax or anything else in the chain

Visit below linked website for help on how to tune your CB installation:

http://www.wearecb.com/how-to-tune-cb-antenna.html
